TAG PRODUCTION TESTER
TESTING MODE
RFID XPLORER
Tag production tester
CISC RFID Xplorer delivers key performance metrics of UHF RFID tags, such as Read and Write range over frequency (meters, feet), Backscatter range over frequency (meters, feet), Minimum tag activation electric field over frequency (V/m), Minimum tag activation power over frequency (dBm), Tag backscatter power over frequency (dBm), Differential radar cross-section over frequency (dBsqm) and the angular sensitivity – tag radiation pattern.
Different Options Available
CISC RFID Xplorer Tag Tester
- CISC RFID Xplorer 200
- RHCP Patch Antenna, 800 – 1000 MHz, 5 dBi
- LHCP Patch Antenna, 800 – 1000 MHz, 5 dBi
- Set of RF cables for RFID Xplorer
- Reference tag including calibration data
- UHF ISO/IEC 18000-63 (Type C) / Gen 2 performance
measurement software for automated tag performance tests
Anechoic Chamber
- Affordable mobile test chamber tailored for RFID tests
Antenna Mounting Set
- Antenna mast and DUT support or bistatic setup
- Including adapters
Supported International Standards
- ISO/IEC 18000-63 Type C
- GS1 EPGglobal Gen2
- ISO/IEC 18047-6 Conformance testing
- ISO/IEC 18046-2 Interrogator performance testing
- ISO/IEC 18046-3 Tag performance testing
- ISO/IEC 29167-10 AES 128 crypto suite
- ISO/IEC 29167-13 Grain-128A crypto suite
- ISO/IEC 29167-19 RAMON crypto suite
- ISO/IEC 19823 Conformance testing
- Chinese GB/T 29768 protocol
- ETSI EN 302 208
- GS1 Tagged item performance protocol – TIPP
- IATA 1740C
- 6C TOC AVI Standard
- SAE International AS5678 Aerospace standard
Brasil Standards
The CISC RFID Measurement products CISC RFID MeETS and CISC RFID Xplorer support the Brasil RFID standards for performance and conformance testing of tags, readers and systems. Furthermore, they support fully automated certification tests according the SINIAV and ARTESP procedures.
The following standards are covered:
The CISC RFID Measurement products CISC RFID MeETS and CISC RFID Xplorer support the Brasil RFID standards for performance and conformance testing of tags, readers and systems. Furthermore, they support fully automated certification tests according the SINIAV and ARTESP procedures.
The following standards are covered:
